Nový Nakladacia rampa AZ RAMP-PRIME PRIME WLO + 12 FULL GALVA Mobil Loading Ramp

Mobile loading ramp designed for industrial use

Brand: AZ RAMP - Type: PRIME PRIME WLO + 12 t FULL GALVA

Capacity: 12 000 Kg

Total Length: 10.15 m

Overall Width Outside: 2,17 m

Interior Width (Useful): 2.00 m

Penetration in the truck: 25cm

Hydraulic crank leveling:

Height Mini: 0.90 m -Height Max: 1.40 m

Hot Galvanized Notched Tray, Anti-Slip 2 Lashing Chains, Centric Quick Hitch Hook, Double Vulkollan Roller Ramp, 2 Adjustable Support Stands, Side Safety Rails

Slopes: Min: 11.25% - Max: 15.56 %

Available Options:*** Safety side guards, height 1,200mm: €1,000 excl. VAT

• Electric support legs: €3,500 excl. VAT
• Crossbeams for securing the unloading of your ramp: €750 excl. VAT
• Forklift tow bar: €750 excl. VAT
• Tarpaulin tunnel: €4,250 excl. VAT

Applications:** Specially designed for industrial use, its use on "coated" or "Mac Adam" type surfaces will be very effective. Loading / Unloading trucks of Plateau or Tautliner type, AZ RAMP - PRIME PRIME WLO + is made of heavy steel, hot dip galvanized. Its full access platform will allow you easy access to all types of material handling equipment, including 3-wheel electric forklifts.
